Indoor High Voltage Vacuum Circuit Breaker

ZN63A(VS1)-24

1.General  Description

ZN63A(VS1)-24 series of Indoor High Voltage Vacuum Circuit Breaker

with embedded poles is 3 phase A.C.50 Hz indoor power distribution equipment with the rated voltage of 24kV. It's used for protecting and controlling the

electrical equipment in fields of industry&mining enterprise. power plants and substation.

The vacuum circuit breaker with spring mechanism is embedded pole that

can greatly improve the reliability of insulation, mechanical and breaking performance.and  own free maintance and long mechanical&electrical life.

The Vacuum Circuit Breaker conforms to national standards and IEC standard. The capability reaches grade of M2-E2-C2.The product is used for many kinds of switchgears such as KYN28-24 and can be fixed installation.

2.Applying  conditions:

Ambient temperature;-10℃----+40℃

Relative humidity:daily average ≤95%,monthly average ≤90%

Seismic intensity ：≤8

Saturated vapor pressure：daily average ≤2.2kPa，monthly average≤1.8kPa；

Altitude：≤1000m；（Not including special requirement）

Service environment：should be avoided fire, explosion risk, serious pollution, chemical corrosion and violent vibration

3.Technical specification

Remark:

      1.No.11 &No.12 is offered while user need.

4.Overall drawing

Overall drawing of fixed circuit breaker

6.Secondary connection diagram

Secondary connection diagram of withdrawable type circuit breaker

Secondary connection diagram of fixed type circuit breaker
